BMC
URS 01 LT One
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL | XS |
|---|---|---|---|---|---|
| Stack | 610mm | 580mm | 560mm | 640mm | 560mm |
| Reach | 420mm | 410mm | 400mm | 430mm | 390mm |
| Headtube length | 172mm | 140mm | 133mm | 204mm | 133mm |
| Headtube angle | 69.5deg | 69.5deg | 69deg | 69.5deg | 69deg |
| BB height | — | — | — | — | — |
| BB drop | 76mm | 76mm | 76mm | 76mm | 76mm |
| Trail | 86mm | 86mm | 84mm | 86mm | 84mm |
| Fork length | 415mm | 415mm | 405mm | 415mm | 405mm |
| Fork offset | 45mm | 45mm | 50mm | 45mm | 50mm |
| Front center | 672mm | 651mm | 643mm | 693mm | 633mm |
| Chainstay length | 430mm | 430mm | 430mm | 430mm | 430mm |
| Wheelbase | 1091mm | 1070mm | 1062mm | 1112mm | 1052mm |
| Top tube | 589mm | 571mm | 555mm | 607mm | 545mm |
| Standover height | 778mm | 758mm | 735mm | 795mm | 727mm |
| Seat tube length | 505mm | 475mm | 445mm | 540mm | 430mm |
| Seat tube angle | 74.5deg | 74.5deg | 74.5deg | 74.5deg | 74.5deg |
Spec geometry
| Geometry | L | M | S | XL | XS |
|---|---|---|---|---|---|
| Crank length | — | — | — | — | — |
| Stem length | — | — | — | — | — |
| Handlebar width | — | — | — | — | — |
| Handlebar reach | — | 70mm | — | — | — |
| Handlebar drop | — | 115mm | — | — | — |
| Saddle width | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — |
| Seatpost offset | — | 0mm | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
URS 01 Premium Carbon with Micro Travel Technology | Gravel+ Geometry | ICS Technology | Integrated Storage | Fender and Rack Mounts | Flat Mount Disc | 12 x 142mm Thru-Axle | UDH Dropout
Suspension
Fork
Micro Travel Technology Suspension Fork, Premium Carbon blades | 20mm travel | Coil spring & Hydraulic damper | Fender mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Brakes
Front brake
Shimano GRX (BR-RX820)
Rear brake
Shimano GRX (BR-RX820)
Front rotor
Shimano RT-CL800 Centerlock, 180mm
Rear rotor
Shimano RT-CL800 Centerlock, 160mm
Drivetrain
Shift levers
Shimano GRX Di2 (BL-RX825 / ST-RX825)
Rear derailleur
Shimano GRX Di2 Wireless (RD-RX827)
Cassette
Shimano Deore XT (CS-M8200-12), 10-51T
Chain
Shimano CN-M8100
Crankset
Shimano GRX (RX820-1) with 40T chainring
Bottom bracket
Shimano Ultegra Press-Fit Bottom Bracket (SM-BB72-41B)
Cockpit
Stem
BMC MSM
Handlebars
BMC HB D4 03, 0, 16 | Alloy 6061 | Gravel geometry | 115mm drop, 70mm reach, 16° flare
Saddle
WTB Gravelier Steel SL | Medium
Seatpost
URS 01 Premium Carbon D-shaped seatpost | 0mm offset | D-Fender compatible
Wheels & Tires
Front wheel
AG 20 | Tubeless Ready | 20mm; AG 20
Rear wheel
AG 20 | Tubeless Ready | 20mm; AG 20
Front tire
WTB Raddler | 44mm
Rear tire
WTB Raddler | 44mm
Weight
Weight
10.5kg (size M as pictured, without pedals, with all accessories)
