Frameset
Frame
Orbea Kemen Top Bar, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible
Fork
SR Suntour XCR34 100mm Air Q15x110
Kemen ADV 20 28mph
The 2025 Orbea Kemen ADV is a heavy-duty urban e-bike designed for commuting and light trekking. Replacing the older Kemen SUV, this generation introduces a longer chassis and a patented integrated cockpit. It comes in both top-bar and mid-bar frame styles, catering to riders who need a robust platform for carrying gear or navigating rough city streets. The core of the platform relies on a high-torque Shimano mid-drive motor paired with an integrated battery and a 100mm suspension fork. It is built for utility and stability rather than lightweight agility, making it a practical choice for daily riders dealing with steep hills, varied surfaces, and heavy loads.
$3,899
Image pending
Build
Size
| Stack | 660.5mm |
| Reach | 463mm |
| Top tube | 643mm |
| Headtube length | 150.6mm |
| Seat tube length | 457.3mm |
Fit and geometry
Orbea significantly updated the Kemen ADV's geometry for this generation, moving away from the steeper, shorter dimensions of the prior SUV model. The chassis now features longer 450mm chainstays and a stretched wheelbase, measuring 1198mm on a size medium. This length prioritizes straight-line tracking and loaded stability over quick, darting maneuvers in tight spaces. A 66.6-degree head tube angle across most sizes further slows the steering, keeping the front end calm at higher commuting speeds.
Rider posture is dictated by a patented four-position integrated cockpit. Orbea replaced the previous generation's wide mountain bike bars with a 720mm urban handlebar featuring a 50mm rise and 9-degree backsweep. This setup places the rider in an upright, relaxed position that improves visibility in traffic and reduces strain on the lower back. The 74-degree seat tube angle keeps the rider centered over the bottom bracket for efficient pedaling. Fit options are broad, with the frame available in both traditional top-bar and step-through mid-bar configurations to accommodate different mobility needs and wardrobe choices.
Full specs
Groupset
Shift levers
Shimano Cues SL-U6000
Rear derailleur
Shimano Cues U6000 GS Shadow
Cassette
Shimano CS-LG400 11-50t 11-Speed
Chain
KMC eGlide
Crankset
FSA CK-752 Shimano EP600/801 170mm, FSA Steel Megatooth 44t w/chainguard
Bottom bracket
Shimano EP600
Front brake
Magura AT2 Hydraulic Disc Easy Route Connection
Rear brake
Magura AT2 Hydraulic Disc Easy Route Connection
Front rotor
null
Rear rotor
null
Wheelset
Front wheel
Alloy, 26c, 32H
Rear wheel
Alloy, 26c, 32H
Front tire
Schwalbe Johnny Watts LR, 60-622, Reflective Tape
Rear tire
Schwalbe Johnny Watts LR, 60-622, Reflective Tape
Cockpit
Stem
null
Handlebars
Orbea Urban, Integ. light, Backsweep 9, Rise 50, Width 720
Saddle
Selle Royal Vivo Ergo
Seatpost
Alloy, 31.6mm, Setback 0
Builds
The Kemen ADV lineup spans 11 builds, divided by component tier, frame style, and motor speed limit (20mph or 28mph). Prices range from $3,399 to $5,099. Every model utilizes the Shimano EP600 motor, meaning riders do not sacrifice torque by choosing an entry-level build. All builds also include a 30kg-rated rear rack, integrated lighting, and Schwalbe Johnny Watts tires.
The entry-level 30 builds feature a 540Wh battery, a coil-sprung Suntour XCR34 fork, and a 9-speed Shimano CUES drivetrain. Moving to the mid-tier 20 models upgrades the battery to 630Wh, swaps the fork to an air-sprung Suntour XCR34, and introduces an 11-speed CUES drivetrain alongside Magura AT2 brakes. The flagship 10 builds move to a Fox 34 Float AWL fork, electronic Shimano CUES Di2 shifting, and Magura MT5N/MT4N brakes. They also add a dropper post, which is absent on the lower tiers. The 20-level builds represent a practical sweet spot, securing the larger battery and air suspension without the premium cost of electronic shifting.
Reviews
Reviewers consistently note the Kemen ADV's stable, predictable ride quality, driven largely by its substantial weight and powerful motor. The 85Nm Shimano EP600 drive unit is the focal point of the riding experience, providing enough torque that "climbing hills became a real pleasure" (Opticycles). This power delivery is smooth and "ultra quiet" (Opticycles), allowing the bike to maintain momentum on steep urban gradients without feeling jerky.
On mixed surfaces, the combination of the suspension fork and high-volume Schwalbe tires effectively mutes vibrations. Testers found the bike to be a "great road companion" (Opticycles) that handles transitions from pavement to gravel with ease. While some riders described the aluminum frame as "sturdy and light" (Opticycles), the consensus points to a heavy overall package. The integrated battery and mid-drive motor create a low center of gravity that aids high-speed tracking, but this mass makes the bike cumbersome to lift onto train racks or maneuver at walking speeds. Additionally, the internal battery design means riders cannot easily remove the pack for off-bike charging, a notable tradeoff for apartment dwellers.
