The Reign Advanced utilizes a modern, aggressive geometry layout that places the rider in a centered, powerful position. A steep seat tube angle, hovering around 77 to 78 degrees depending on the flip-chip setting, keeps the rider's weight forward during steep climbs. This prevents the rearward bias often felt on long-travel bikes and helps maintain front-wheel traction.
Handling is heavily influenced by the three-position flip chip at the upper rocker. In the lowest setting, the head angle drops to a slack 62.7 degrees, maximizing high-speed stability for steep, shuttle-accessed descents. The middle setting raises the bottom bracket slightly and steepens the angles, which many riders prefer for technical climbing and general trail riding to avoid pedal strikes. The highest setting is primarily used to preserve bottom bracket clearance when swapping to a 27.5-inch rear wheel.
Across all sizes, the chainstays remain relatively short at roughly 443mm. This consistent rear center helps retain a degree of agility, allowing riders to pivot the rear end through tight switchbacks despite the long overall wheelbase. The cockpit features a low stack height and a short 40mm stem, encouraging an aggressive, forward-leaning posture.
