Salsa
Rangefinder Advent X 27.5+
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | Large | Medium | Small | X-Large | X-Small |
|---|---|---|---|---|---|
| Stack | 620.1mm | 611mm | 606.4mm | 629.3mm | 601.9mm |
| Reach | 470.4mm | 444.4mm | 421.5mm | 494.3mm | 400.6mm |
| Headtube length | 115mm | 105mm | 100mm | 125mm | 95mm |
| Headtube angle | 68.5deg | 68.6deg | 68.6deg | 68.5deg | 68.6deg |
| BB height | — | — | — | — | — |
| BB drop | 61.8mm | 61.9mm | 62mm | 61.7mm | 62mm |
| Trail | — | — | — | — | — |
| Fork length | 501mm | 501mm | 501mm | 501mm | 501mm |
| Fork offset | 501mm | 501mm | 501mm | 501mm | 501mm |
| Front center | — | — | — | — | — |
| Chainstay length | 439mm | 439mm | 439mm | 439mm | 439mm |
| Wheelbase | 1179.4mm | 1149.6mm | 1124.7mm | 1207.1mm | 1101.9mm |
| Top tube | 641.9mm | 613.3mm | 589mm | 668.5mm | 566.7mm |
| Standover height | 779.1mm | 747.2mm | 708.3mm | 808.7mm | 688.6mm |
| Seat tube length | 470mm | 431mm | 381mm | 508mm | 355mm |
| Seat tube angle | 74.5deg | 74.6deg | 74.6deg | 74.5deg | 74.6deg |
Spec geometry
| Geometry | Large | Medium | Small | X-Large | X-Small |
|---|---|---|---|---|---|
| Crank length | 175mm | 175mm | 170mm | 175mm | 170mm |
| Stem length | 60mm | 60mm | 60mm | 60mm | 60mm |
| Handlebar width | 800mm | 800mm | 750mm | 800mm | 750mm |
| Handlebar reach | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — |
| Saddle width | 142mm | 142mm | 142mm | 142mm | 142mm |
| Dropper post travel | — | — | — | — | — |
| Seatpost offset | 0mm | 0mm | 0mm | 0mm | 0mm |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Rangefinder Aluminum
Suspension
Fork
SR Suntour XCM32 Boost, coil, NLO, DS, 120mm
Brakes
Front brake
Shimano MT200 OR Tektro M520 hydraulic disc
Rear brake
Shimano MT200 OR Tektro M520 hydraulic disc
Front rotor
Shimano RT10 Center Lock, 160mm
Rear rotor
Shimano RT10 Center Lock, 160mm
Drivetrain
Shift levers
microSHIFT Advent X M9605
Rear derailleur
microSHIFT Advent X M6205
Cassette
microSHIFT Advent X H104, 10-speed, 11-48T
Chain
Shimano HG54
Crankset
FSA Alpha Drive, 30T
Bottom bracket
FSA 124.5mm bottom bracket
Cockpit
Stem
Salsa Guide 31.8, 60mm, 6°
Handlebars
Salsa Salt Flat 31.8, 750mm (XS-SM) / Salsa Rustler 31.8, 800mm (M-XL)
Grips
Salsa File Tread
Saddle
WTB Volt Medium, steel rails, 142 x 265mm
Seatpost
Salsa Guide 30.9, 0 offset
Wheels & Tires
Front wheel
Shimano MT400 Center Lock hub, 15x110mm TA / WTB ST i40 32h 27.5" rim
Rear wheel
Shimano MT200 Center Lock hub, 10x141mm QR / WTB ST i40 32h 27.5" rim
Front tire
Maxxis Rekon 27.5 x 2.8", EXO, wire bead (not tubeless compatible)
Rear tire
Maxxis Rekon 27.5 x 2.8", EXO, wire bead (not tubeless compatible)
Weight
Weight
33 lb (with tubes, no pedals) for Medium
