Canyon
Grizl 6 RAW Shimano GRX RD-RX400
Gallery
Images
detail
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 2XL | 2XS | 3XS | L | M | S | XL | XS |
|---|---|---|---|---|---|---|---|---|
| Stack | 644mm | 522mm | 512mm | 605mm | 579mm | 556mm | 626mm | 537mm |
| Reach | 436mm | 377mm | 372mm | 409mm | 402mm | 397mm | 427mm | 382mm |
| Headtube length | 205mm | 122mm | 115mm | 166mm | 141mm | 121mm | 186mm | 135mm |
| Headtube angle | 72.5deg | 69.75deg | 69deg | 72deg | 71.5deg | 70.25deg | 72.5deg | 70.5deg |
| BB height | — | — | — | — | — | — | — | — |
| BB drop | 75mm | 60mm | 60mm | 75mm | 75mm | 75mm | 75mm | 60mm |
| Trail | — | — | — | — | — | — | — | — |
| Fork length | — | — | — | — | — | — | — | — |
| Fork offset | — | — | — | — | — | — | — | — |
| Front center | — | — | — | — | — | — | — | — |
| Chainstay length | 435mm | 420mm | 420mm | 435mm | 435mm | 435mm | 435mm | 420mm |
| Wheelbase | 1089mm | 1009mm | 1007mm | 1055mm | 1045mm | 1044mm | 1074mm | 1012mm |
| Top tube | 627mm | 532mm | 524mm | 588mm | 574mm | 562mm | 612mm | 541mm |
| Standover height | 884mm | 730mm | 709mm | 835mm | 807mm | 780mm | 860mm | 752mm |
| Seat tube length | 612mm | 432mm | 402mm | 552mm | 522mm | 492mm | 582mm | 462mm |
| Seat tube angle | 73.5deg | 73.5deg | 73.5deg | 73.5deg | 73.5deg | 73.5deg | 73.5deg | 73.5deg |
Spec geometry
| Geometry | 2XL | 2XS | 3XS | L | M | S | XL | XS |
|---|---|---|---|---|---|---|---|---|
| Crank length | 175mm | 170mm | — | 172.5mm | 172.5mm | 170mm | 175mm | 170mm |
| Stem length | 70mm | 50mm | — | 60mm | 60mm | 60mm | 70mm | 50mm |
| Handlebar width | 440mm | 420mm | — | 440mm | 440mm | 420mm | 440mm | 420mm |
| Handlebar reach | — | — | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — | — | — |
| Saddle width | 145mm | 145mm | — | 145mm | 145mm | 145mm | 145mm | 145mm |
| Dropper post travel | — | — | — | — | — | — | — | — |
| Seatpost offset | 20mm | 20mm | — | 20mm | 20mm | 20mm | 20mm | 20mm |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Canyon Grizl AL (aluminium, Gravel Pro geometry, 12x142mm, 50mm tyre clearance)
Suspension
Fork
Canyon FK0087 CF Disc (carbon, 12x100mm, 1 1/4" steerer, 54mm tyre clearance, triple-mount)
Brakes
Front brake
Shimano GRX RX400 hydraulic disc brake
Rear brake
Shimano GRX RX400 hydraulic disc brake
Front rotor
Shimano RT-CL700, 160mm (Center Lock)
Rear rotor
Shimano RT-CL700, 160mm (Center Lock)
Drivetrain
Shift levers
Shimano GRX RX400 (shift/brake levers)
Rear derailleur
Shimano GRX RD-RX400 (long cage)
Front derailleur
Shimano GRX FD-RX400-F
Cassette
Shimano HG500 (10-speed, 11-34T)
Chain
KMC X10-93 (10-speed) with KMC Connection Link
Crankset
Shimano GRX FC-RX600-10 (2x, 10-speed)
Bottom bracket
Token Ninja Lite BB4124 (PF86.5)
Cockpit
Stem
Canyon ST0035 (31.8mm clamp, 1 1/4" steerer, aluminium)
Handlebars
Canyon HB0064 Ergo (flared drops, 31.8mm clamp, aluminium)
Grips
Canyon Ergospeed Gel handlebar tape (black)
Saddle
Selle Italia Model X (145mm)
Seatpost
Canyon SP0043 VCLS CF (carbon, 20mm setback, VCLS)
Wheels & Tires
Front wheel
DT Swiss Gravel LN (12x100mm, Center Lock, aluminium rim, 25mm rim height, 24mm inner width)
Rear wheel
DT Swiss Gravel LN (12x142mm, Center Lock, Shimano freehub, aluminium rim, 25mm rim height, 24mm inner width)
Front tire
Schwalbe G-One RX PRO V-Guard TLR, 45mm
Rear tire
Schwalbe G-One RX PRO V-Guard TLR, 45mm
