Trek
Slash 8 Gen 6
Gallery
Images
No images available yet.
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | ML | S | XL |
|---|---|---|---|---|---|
| Stack | 641mm | 623mm | 632mm | 588mm | 659mm |
| Reach | 488mm | 448mm | 468mm | 430mm | 513mm |
| Headtube length | 120mm | 100mm | 110mm | 100mm | 140mm |
| Headtube angle | 63.3deg | 63.3deg | 63.3deg | 63.5deg | 63.3deg |
| BB height | 351mm | 351mm | 351mm | 352mm | 351mm |
| BB drop | 27mm | 27mm | 27mm | 1mm | 27mm |
| Trail | 143mm | 143mm | 143mm | 132mm | 143mm |
| Fork length | — | — | — | — | — |
| Fork offset | 43mm | 43mm | 43mm | 43mm | 43mm |
| Front center | — | — | — | — | — |
| Chainstay length | 434mm | 429mm | 434mm | 429mm | 439mm |
| Wheelbase | 1278mm | 1224mm | 1253mm | 1195mm | 1312mm |
| Top tube | 628mm | 578mm | 605mm | 548mm | 658mm |
| Standover height | 767mm | 766mm | 766mm | 727mm | 768mm |
| Seat tube length | 435mm | 400mm | 420mm | 390mm | 470mm |
| Seat tube angle | 73.8deg | 73.8deg | 73.8deg | 74deg | 73.8deg |
Spec geometry
| Geometry | L | M | ML | S | XL |
|---|---|---|---|---|---|
| Crank length | 165mm | 165mm | 165mm | 165mm | 165mm |
| Stem length | 35mm | 35mm | 35mm | 35mm | 35mm |
| Handlebar width | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — |
| Saddle width | — | — | — | — | — |
| Dropper post travel | 170mm | 170mm | 170mm | 100mm | 170mm |
| Seatpost offset | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Alpha Platinum Aluminum, high main pivot, idler pulley, internal storage, angle-adjust headset, adjustable leverage rate, integrated frame protection, internal routing, alloy rocker link, ISCG 05, Active Braking Pivot, UDH, 148x12mm thru axle, 170mm travel
Suspension
Rear shock
Fox Performance Float X, 2-position damper, 230mm x 65mm
Fork
Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt-X axle, 170mm travel
Brakes
Front brake
Shimano 4-piston hydraulic disc, M6100 lever, M6120 caliper
Rear brake
Shimano 4-piston hydraulic disc, M6100 lever, M6120 caliper
Front rotor
Shimano RT66, 6-bolt, 203mm
Rear rotor
Shimano RT66, 6-bolt, 203mm
Drivetrain
Shift levers
Shimano XT M8100, 12-speed
Rear derailleur
Shimano XT M8100, long cage
Cassette
Shimano XT M8100, 12-speed, 10-51T
Chain
Shimano SLX M7100, 12-speed
Crankset
Shimano Deore M6120, 30T, 55mm chainline, 165mm length
Bottom bracket
Shimano BB-MT501, BSA
Cockpit
Stem
Bontrager Elite, 35mm clamp, 0 degree, 35mm length
Handlebars
Bontrager Line, alloy, 35mm clamp, 27.5mm rise, 780mm width (alt spec listed: 820mm width)
Grips
Bontrager XR Trail Pro, alloy lock-on (alt spec listed: Trek Line Comp, nylon lock-on)
Saddle
Bontrager Verse P3, chromoly rails
Seatpost
Bontrager Line Dropper, internal routing, 34.9mm (Size S: 100mm travel, 310mm length; Sizes M/ML/L/XL: 170mm travel, 450mm length)
Wheels & Tires
Front wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle (Size S: 27.5"; Sizes M/ML/L/XL: 29")
Rear wheel
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, Shimano Micro Spline freehub (listed as 27.5")
Front tire
Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi (27.5x2.50" on S/M/ML/L/XL; 29x2.50" on M/ML/L/XL)
Rear tire
Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi (27.5x2.50" on S/M/ML/L/XL; 29x2.50" on M/ML/L/XL)
Weight
Weight
Size M: 16.68 kg / 36.78 lbs (with TLR sealant, no tubes)
